| Model | Power | Speed | Theoretic Displacement | Max Pressure | Tank | Weight | Dimensions | |||
|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|||
| Hp | Kw | Rpm | L/min | Cfm | Bar | Psi | L/Gal | Kg | LxWxH(cm) | |
| W-0.36/8 | 4 | 3 | 1050 | 503 | 17.8 | 8 | 115 | 100/26,5 | 93 | 116*46*81 |
| W-0.36/8 | 4 | 3 | 10B0 | B03 | 17.8 | 8 | 115 | 150/40 | 112 | 131*46*88 |
| W-0.36/8 | 4 | 3 | 1050 | 503 | 17.8 | 8 | 115 | 200/53 | 127 | 145*55*100 |
| W-0.67/8 | 7.5 | 5.5 | 850 | 859 | 30.3 | 8 | 115 | 120/32 | 139 | 125*55*94 |
| W-0.67/8 | 7.5 | 5.5 | 850 | 859 | 30.3 | 8 | 115 | 200/53 | 185 | 137*57*101 |
| W-0.9/8 | 10 | 7.5 | 850 | 1087 | 38.4 | 8 | 115 | 170/45 | 174 | 147*54*95 |
| W-0.9/8 | 10 | 7.5 | 8B0 | 1087 | 38.4 | 8 | 115 | 200/53 | 190 | 136*56*102 |
| W-0.9/8 | 10 | 7.5 | 850 | 1087 | 38.4 | 8 | 115 | 300/80 | 220 | 166*57*108 |
| W-l.0/12.5 | 10 | 7.5 | 850 | 850 | 30 | 12.5 | 178 | 300/80 | 302 | 180*62*115 |
| W-l.6/8 | 15 | 11 | 800 | 1807 | 63.8 | 8 | 115 | 300/80 | 430 | 161*71*126 |
| W-l.6/12.5 | 15 | 11 | 800 | 1000 | 35.3 | 12.5 | 178 | 300/80 | 305 | 180*71*122 |
| W-2.0/8 | 20 | IB | 800 | 2440 | 86.2 | 8 | 115 | 300/80 | 482 | 161*75*136 |
| W-2.0/12.5 | 20 | 15 | 800 | 1500 | 52.9 | 12.5 | 178 | 500/132 | 482 | 196*75*141 |
| V-l.05/12.5 | 10 | 7.5 | 750 | 1325 | 46.8 | 12.5 | 178 | 300/80 | 325 | 180*71*122 |
