| Model | Power | Speed | Theoretic Displacement | Max Pressure | Tank | Weight | Dimensions | ||
|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
||
| W | Rpm | L/min | Cfm | Bar | Psi | L/Gal | Kg | LxWxH(cm) | |
| BW600-9 | 600 | 1380 | 110 | 3.9 | 8 | 115 | 9/2.38 | 14.5 | 47*20*51 |
| BW600-18 | 600 | 1380 | 110 | 3.9 | 8 | 115 | 18/4.8 | 21 | 52*25*50 |
| BW600-24 | 600 | 1380 | 110 | 3.9 | 8 | 115 | 24/6.5 | 21.5 | 54*25*51 |
| BW600-30 | 600 | 1380 | 110 | 3.9 | 8 | 115 | 30/8 | 22.5 | 60*25*51 |
| BW600-24 | 800 | 1380 | 145 | 5.1 | 8 | 115 | 24/6.5 | 22 | 54*25*53 |
| BW600-30 | 800 | 1380 | 145 | 5.1 | 8 | 115 | 30/8 | 23 | 60*25*53 |
| BW800-24 | 800 | 1380 | 145 | 5.1 | 8 | 115 | 24/6.5 | 22 | 54*25*53 |
| BW800-30 | 800 | 1380 | 145 | 5.1 | 8 | 115 | 30/8 | 23 | 60*25*53 |
| BW800-50 | 800 | 1380 | 145 | 5.1 | 8 | 115 | 50/13.2 | 27 | 68*31*59 |
| BW1100-50 | 1100 | 1380 | 220 | 7.8 | 8 | 115 | 50/13.2 | 32 | 68*31*68 |
| BW1500-50 | 1500 | 1380 | 280 | 9.9 | 8 | 115 | 50/13.2 | 35 | 68*31*68 |
| BWD600-35 | 600 | 1380 | 110 | 3.9 | 8 | 115 | 35/9.2 | 26 | 65*28*65 |
| BWD800-35 | 800 | 1380 | 145 | 5.1 | 8 | 115 | 35/9.2 | 28 | 65*28*65 |
| BWD1100-50 | 1100 | 1380 | 220 | 7.8 | 8 | 115 | 50/13.2 | 32 | 68*31*70 |
| BDW1500-50 | 1500 | 1380 | 280 | 9.9 | 8 | 115 | 50/13.2 | 34 | 68*31*70 |
